Low Air Flow Solution - Air Condition Return Air Vents

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

·IEF technology, 0 space occupation, 0 material consumption, 0 noise and 0 ozone;

·Remove 99% of PM2.5, methanal, influenza virus and other air pollutants.

·Prevent influence on return air effect of air-conditioning with ultralow air resistance;

·Intelligent control, linked to fan coil, purify when air flows and stop when air stops;

·Concealed in return air inlet of central air-conditioning without destroying decoration and occupying floor space;

·Comprehensively adaptive to fan coils of internal unit etc.

DescriptionSingle IFFC UnitSingle IFFC Unit
Size ( W x H x Thickness)/mm660*241*90960*241*901170*241*901470*241*90
Applied air volume(m3/h)(@0.5-1-1.5m/s)170~340~510280~570~850340~690~1020460~920~1360
One-pass purification rate of PM2.5 (@0.5-1-1.5m/s)98-93-90%
Equipment Pressure(Pa)2.5-9-15

Disinfection MethodCertified Micro-electrosatic-based disinection
Bacteria removal rate99.9% Staphylococcus albicans
Disinfection Time(min)60
Rated temperature(℃)4~52
Power supply(V/HZ)220/50
Rated Power(W)5678
Status IndicationRunning/Cleaning
Accessory FunctionsPneumatical Switch/M8 methanal filter (Optional)
Applied Product Standards:GB15982-2012;WS/T 648-2019;《Disinfection Technology Rule》(Ministry of Health,2002)Q31/0113000146C002-2019
